SANYO scroll compressor
* The CGX discharge-bypass valve is a kind of load adjust component for the refrigerating systemwith a non-adjustable compressor.
* The CGX discharge-bypass valve can be used as automatic expansion valve under fixed pressure to maintain the fixed evaporation pressure (temperature).
* The CGXdischarge-bypass valve is capable of maintaining the minimum evaporating pressure.
* ODF connecting.
* Suitable for HFC and HCFC.
* Maximum working pressure: 28bar.
|
Model |
Adjustment range |
Cooling Capability (KW) |
Set pressure |
Connecting size |
||
|
R134a |
R22/R407c |
Inlet |
Outlet |
|||
|
CGX-05 |
0～0.7MPa |
1.5 |
2.8 |
0.4MPa |
￠8 ODF |
￠10 ODM |
|
CGX-08 |
2.4 |
4.5 |
||||
|
CGX-10 |
3 |
5.6 |
||||
|
CGX-15 |
4.2 |
8.4 |
||||
|
CGX-20 |
5.7 |
11.2 |
||||
|
CGX-30 |
8.5 |
16.8 |
||||
|
CGX-20L |
0.03～0.6MPa |
7 |
11 |
3/8"SAE Flare |
1/2" SAE Flare |
|
|
CGX-20H |
7 |
11 |
3/8" ODF |
1/2" ODF |
||
|
CGX-40 |
14 |
22.5 |
1/2" ODF |
5/8" ODF |
||
|
CGX-100 |
30 |
40 |
||||
